Main Features:
1. Fully Servo motors driven
2. Fully automatically controlled by PLC
3. Accurately inspect the printing defects for printed films.
4. Easy and smart operation.
Main mechanical configuration:
1, Main body unit:
1. Machine’s main body adopts cast iron and steel structure.(cast iron after secondary operation and setting treatment)
2. Main driving roller adopts seamless steel pipe (after tempering, surface hardening, chrome plated,mirror surface, dynamic balance treatment)
3. Main driving press roller adopts rubber roll (nitrile-butadiene rubber)
4. Material guide rollers adopts steel rolls (aluminum alloy) and rubber roll (nitrile-butadiene rubber)
5. Driving mode of main body and rewind shafts adopt synchronizing wheel and belt.
2, Unwinding unit:
1. Unwind unit adopts one-piece structure.
2. It adopts removable bracket with ball slider.
3. Non-axial Air pressure and get way with Air Chuck, which is caught taking raw materials fast, easy loading, single-person operation(shaft-less type)
4. 1 set bias adjustable device can fine tune left and right, forward and backward through hand wheel.
5. Unwind tension’s actuator is 1 set Taiwan brand DANMA servo motor. through PLC to achieve a constant tension.
6. LPC uses Taiwanese brand PAUSOURCE corrective device, it can achieve guide function by material’s edge and printing line.
3. Rewinding unit:
1. Rewind unit adopts one-piece structure.
2. It adopts removable bracket with ball slider.
3. Rewind tension’s actuator is 1 set Taiwan brand DANMA servo motor. Through PLC to achieve a constant tension.
4. 1 set bias adjustable device can fine tune left and right, forward and backward through hand wheel.
5. Non-axial Air pressure and get way with Air Chuck, who is caught taking raw materials fast, easy loading, single-person operation(shaft-less type)
